eneloop

9V/6F22

Soshine New 9V Li-po Rechargeable Battery: 650mAh 7.4V
Soshine New 9V Li-po Rechargeable Battery: 650mAh 7.4V
Product Overview
Can charger by other 9V charger
Slim design(15.4mm)
Ready to use at any time
Model:  Li-7.4V-650S
Contact us:siling.soshine@gmail.com
or use this form to request a quote.
  Your email:
  Additional Comments:
  Check:
Description


New 9V Li-po Rechargeable Battery: 650mAh
7.4V

Bar Code: 6951151510211

Model: Li-7.4V-650S



Can charged by other 9V charger
Slim design(15.4mm)
Ready to use at any time



Specification:

Type:      Rechargeable  Li-Po
Dimension:(48.5+-0.5)*(26.1+-0.2)*(15.4+-0.3)mm (max)
C5mAh:  630(mini)
C5mA:    650mAh
Nominal Voltage:    7.4V
Capacity : Nominal   650mAh
               Minimum  630mAh

Internal resistance: 144-150 mΩ
when discharged at 0.2C5mA to 5.5V
Recommended Charging Conditions:0.2C5mA charge termination control parameters taper current 0.01C5mA at 8.4V
Service Life: 1,000 cycles(>=60% C5mAh,0.2C discharge)
Weight: 28 g (1 cell), 67 (2 cells with package)
Charging Voltage:  8.4+/-0.15V
Ambient Temperature Range
Charging :      0-45 centigrade
Discharging:  -20 to +60 centigrade
Storage :       -20 to +40 centigrade



Note:
(1) The batteries should be stored at room temperature,charged to about 30% to 50% of capacity.
(2) During long term storage,in order to ensure the battery to maintain the capacity level,we suggest Li-ion batteries should be charged and discharged once every 6 months.




Time:2012-07-1  Views:13035
